Description
Product Description
Fabtech Performance Shocks have been designed to work in conjunction with each of our suspension systems, resulting in superior ride control. Features include high velocity 9-stage valving for excellent dampening capabilities and a closed cell insert to reduce shock fade at high speeds. A twin-tube shock absorber consists of a thin wall inner pressure tube and outer reserve tube. The inner tube houses the valving components, piston and base valve and is where the damping forces are generated. The outer tube acts as a reservoir for displaced fluid from the shaft volume during the compression stroke. Also contained in the outer tube is a foam sleeve or gas bag that contracts and expands with respect to shaft displacement to eliminate air pockets and increase the performance of the shock.Shock Absorber; Performance Twin Tube; Hydraulic; One Year Warranty; Not Adjustable; Without Shock Boots; Single
Features & Benefits
- Twin Tube Hydraulic Construction
- Hardened Chrome Piston Rod
- Closed Cell Foam Insert To Reduce Shock Fade At High Speeds
- High Flow 9 Stage Valving For Excellent Dampening Capabilities
- Limited 3 Year Warranty
Attributes
- Type: Hydraulic
- With Coil Spring: No
- Extended Length (IN): 26.05 Inch
- Compressed Length (IN): 15.4 Inch
- Upper Mounting Style: Stud
- Lower Mounting Style: Eyelet
- Adjustable Valving: No
- Quantity: Single
- Universality: Semi-Universal
- Internal Design: Twin Tube
- Body Color: White
- Rod Diameter (IN): 9/16 Inch
- Valving Type: 9 Stage High Velocity Valving
- Rod Material: Steel
- Body Material: Stainless Steel
- With Reservoir: No
- Includes Dust Shield: No
- Includes Hardware: No
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
